Trajan's Column is a Roman triumphal column in Rome, Italy, that commemorates Roman emperor Trajan's victory in the Dacian Wars. It was probably constructed under the supervision of the architect Apollodorus of Damascus at the order of the Roman Senate. It is located in Trajan's Forum, built near the Quirinal Hill, north of the Roman Forum. Completed in AD 113, the freestanding column is most famous for its spiral bas relief, which artistically represents the wars between the Romans and Dacians (101–102 and 105–106). Its design has inspired numerous victory columns, both ancient and modern.
The structure is about 30 metres (98 feet) in height, 35 metres (115 feet) including its large pedestal. The shaft is made from a series of 20 colossal Carrara marble drums, each weighing about 32 tons, with a diameter of 3.7 metres (12.1 feet). The 190-metre (620-foot) frieze winds around the shaft 23 times. Inside the shaft, a spiral staircase of 185 steps provides access to a viewing platform at the top. The capital block of Trajan's Column weighs 53.3 tons, which had to be lifted to a height of c. 34 metres (112 feet).
Ancient coins indicate preliminary plans to top the column with a statue of a bird, probably an eagle, but after construction, a statue of Trajan was put in place; this statue disappeared in the Middle Ages. On December 4, 1587, the top was crowned by Pope Sixtus V with a bronze figure of St. Peter, which remains to this day. The column was originally flanked by two libraries, which may have contained Trajan's scroll-written despatches from his Roman-Dacian Wars. Filippo Coarelli suggests that such scrolls are the basis both of the column's design and its spiraling, sculpted narrative. The column shows 2,662 figures, and 155 scenes; Trajan himself appears on the column 58 times.
The continuous helical frieze winds 23 times from base to capital, and was in its time an architectural innovation. The design was adopted by later emperors such as Marcus Aurelius. The narrative band expands from about 1 metre (3.3 feet) at the base of the column to 1.2 metres (3.9 feet) at the top.
The scenes unfold continuously. Often a variety of different perspectives are used in the same scene, so that more can be revealed (e.g., a different angle is used to show men working behind a wall).
As French archaeologist Paul Veyne notes, the relief could be read "vertically" from below, with the figure of the emperor recognizable across the bands of images—just as, on the Colonne Vendome, Napoleon's figure can be picked up, scene after scene. Additionally, the two libraries surrounding it provided platforms from which to observe the Column if the viewer stood on the top floors, making the complete view of frieze much more visible.
Battle scene between the Roman and Dacian armies
While there is certainly evidence that the Column was not put in an ideal spot for visibility, it is impossible to reject the Column as some form of a glorification structure. There is the significant point that the Column was extremely challenging to construct, and so it is unlikely that it would have been placed in the Forum with the intentions of being hidden or out of plain sight.
There is also the important idea of the Column as a symbol for Trajan. Trajan's ashes were buried in a chamber at the base of the Column. At the top of the Column was a statue of Trajan. The ground level of the Forum, which is a center of life for Romans, is where the earthly remains of Trajan are buried. The Column from the base goes up, taking us through Trajan's triumph in the Dacian wars, and (as originally constructed) finishes with a statue of Trajan above the forum. If we consider the practice of deification of emperors, which was expected during this time period, especially of glorious Trajan, it is hard to ignore the symbolism here. Trajan's earthly remains stay in the Forum with the Roman people, while his conquests ascend him up into the heavens. It would be hard to prove this set up as a coincidence, thus the Column should be regarded in some sense as a symbol of glorification.
Erection of the Vatican obelisk in 1586 by means of a lifting tower. A similar arrangement was presumably used for the construction of Trajan's Column, but with less available space and thus manpower.
It is assumed that the column drums were lifted by cranes into their place. Ancient sources, as well as a substantial body of archaeological evidence, show that Roman engineers were capable of raising large weights clear off the ground. The typical drum of Trajan's Column weighs c. 32 t, while the capital, the heaviest block above the base and pedestal, is even at 53.3 t, which had to be lifted 34 m high. To save weight, the treads had probably been carved out before either at the quarry or in situ.
Erection of the Vatican obelisk in 1586 by means of a lifting tower. A similar arrangement was presumably used for the construction of Trajan's Column, but with less available space and thus manpower.
Even so, for such loads, the typical Roman treadwheel crane, which could only reach a maximum height of 15 to 18 metres (49–59 feet) in any event, was clearly inadequate. Instead, a tower-like wooden construction was erected around the building site, in the midst of which the marble blocks were raised by a system of pulleys, ropes and capstans; these were powered by a large workforce of men and possibly also draught animals, spread out on the ground. According to modern calculations, eight capstans were needed to hoist the 55 t base block, while the length of rope required for the highest drums measured some 210 metres (690 feet) assuming two-block pulleys.
Such a lifting tower was later also used to great effect by the Renaissance architect Domenico Fontana to relocate obelisks in Rome. From his report, it becomes obvious that the coordination of the lift between the various pulling teams required a considerable amount of concentration and discipline, since, if the force was not applied evenly, the excessive stress on the ropes would make them rupture. In case of Trajan's Column, the difficulties were exacerbated even further by the simultaneous work on the neighbouring Basilica Ulpia, which limited the available space so that the capstan crews had proper access only from one side.
The inscription at the base of the column in finest lettering reads:
SENATVS·POPVLVSQVE·ROMANVS
IMP·CAESARI·DIVI·NERVAE·F·NERVAE
TRAIANO·AVG·GERM·DACICO·PONTIF
MAXIMO·TRIB·POT·XVII·IMP·VI·COS·VI·P·P
AD·DECLARANDVM·QVANTAE·ALTITVDINIS
MONS·ET·LOCVS·TANT<IS·OPER>IBVS·SIT·EGESTVS
Translated, the inscription reads:
The Senate and people of Rome to the emperor Caesar, son of the divine Nerva, Nerva Traianus Augustus Germanicus Dacicus, pontifex maximus, in his 17th year in the office of tribune, having been acclaimed 6 times as imperator, 6 times consul, pater patriae, to demonstrate of what great height the hill and place was removed for such great works.
Two examples of Dupondius struck 114–116 AD, showing Trajan's column with the original statue on top and his portrait
It was believed that the column was supposed to stand where the saddle between the Capitoline and Quirinal Hills used to be, having been excavated by Trajan, but excavation has revealed that this is not the case. The saddle was where Trajan's Forum and Trajan's Market stood. Hence, the inscription refers to the Trajan's entire building project in the area of the Imperial fora.
